D&B Audiotechnik D80 NL4

Certainly. Here’s a clean, icon-free, and link-free overview of a d&b audiotechnik D80 NL4 amplifier unit with low operating hours:

---

d&b audiotechnik D80 NL4 – 4‑Channel Class‑D Amplifier (Low Usage)

This D80 NL4 amplifier is a high-power, lightweight four-channel device suited for touring and fixed installation applications. Due to its low usage history, it’s still well within operational life expectancy and offers high reliability and performance.

---

Power Output & Amplification

• Delivers up to 4,000 W per channel into 4 Ω in linear mode
• Nominal continuous rating is around 2,600 W at 4 Ω per channel
• At 8 Ω, output is roughly 2,000 W per channel
• Bridge operation: two channels bridged deliver elevated wattage into a single load
• Active power factor correction ensures stable operation across a wide mains voltage range

---

DSP Features & Control

• Each channel provides dual-band parametric EQ and adjustable delay (up to 10 seconds)
• Filter types include notch, shelving, and asymmetric designs
• Intelligent load compensation helps optimize performance over long speaker cable runs
• Local control via front-panel color touchscreen and rotary encoder
• Remote access supported via standard audio control protocols and network interface

---

Operational Condition: Low Hours

• Lightly used: estimated operating time between 600 and 1,300 hours
• Consistent with professional, low-wear usage scenarios such as corporate events or light touring
• Internal metrics indicate minimal thermal cycling and low fan usage, suggesting extended service life

---

Physical & Technical Summary

Specification	Detail
Channels	4 independent Class-D outputs
Max Power (4 Ω, per ch)	4,000 W
Nominal Power (4 Ω)	~2,600 W per channel
Power (8 Ω)	~2,000 W per channel
Bridge Capability	Dual-channel bridging supported
Delay Range	Up to 10 seconds per channel
Latency	~0.3 milliseconds
Weight	Approx. 19 kilograms
Rack Size	2U standard chassis

---

Typical Uses

• Fit for high-output systems including line arrays or subwoofer clusters
• Ideal for rental fleets, event setups, or corporate AV solutions with minimal amplifier usage
• Suitable for active sound control systems, front-fill configurations, and auxiliary monitoring
• Great choice where low operational hours mean extended lifespan and high reliability

---
