Mc2 Delta 80 DSP
€2,000.00
The MC² Delta 80 DSP combines robust Class-D amplification with advanced digital processing and optional Dante connectivity. It’s built for professionals who need efficiency, power, and full DSP control in a single unit. With its precision audio quality and network integration, it’s an ideal solution for both touring and fixed sound systems.
MC² Delta 80 DSP – 4-Channel Power Amplifier with Integrated DSP
The MC² Delta 80 DSP is a high-output, four-channel amplifier designed for demanding professional audio applications. It features onboard digital signal processing, network control options, and reliable Class-D power in a compact 2U chassis. Built for touring and installation, it offers pristine sound quality, advanced protection, and versatile configuration options.
Amplification and Output Power
- Four-channel Class-D architecture
- Power per channel:
- 1000 W at 8 ohms
- 2000 W at 4 ohms
- 2200 W at 2.7 ohms
- 2000 W at 2 ohms
- Bridge mode:
- 4000 W into 8 ohms
- 4000 W into 4 ohms
- Excellent efficiency and thermal performance, even under continuous load
- Designed for high-headroom, full-range systems, subs, or multi-way speaker configurations
DSP Features
- Integrated high-resolution DSP engine
- Adjustable parametric EQ, delay, crossover filters, and limiters on each channel
- Configurable FIR and IIR filter combinations
- Flexible input/output routing and grouping
- Local and network-based control of DSP parameters
- Four auxiliary DSP channels for advanced routing or signal duplication
Control and Networking
- USB, Ethernet, and RS-485 connectivity
- Compatible with dedicated software for control and monitoring
- Optional Dante audio-over-IP module allows for audio and control over a single CAT5e cable
- Input source selection per channel: analog, Dante, or auxiliary DSP
- Remote preset recall, gain adjustment, and mute/group control
Protection and Monitoring
- Short circuit, thermal, overvoltage, and DC protection
- Output stage monitored in real time for fault detection
- Clip limiting and peak voltage protection to safeguard loudspeakers
- Intelligent fan control with front-to-rear airflow and low operating noise
- Real-time metering for signal, limiter, temperature, and status
Electrical and Physical Specifications
| Feature | Specification |
|---|---|
| Amplifier Class | Class-D, four-channel |
| Rack Size | 2U (88 mm height) |
| Depth | Approx. 428 mm |
| Weight | Approx. 10 kg |
| Input Sensitivity | 8.8 dBu for full output |
| Frequency Response | 20 Hz – 20 kHz (±0.5 dB) |
| THD | < 0.08% at 1 kHz, < 0.1% full-range |
| Signal-to-Noise Ratio | > 108 dB |
| Power Supply | Universal (100–240 VAC) with PFC |
| Standby Power Consumption | Less than 50 W |
Use Cases
- Touring racks with DSP-controlled loudspeaker arrays
- Live venues, theaters, and stadiums
- Fixed installations with Dante-based distribution
- Multi-way systems requiring local DSP and high channel density
- Projects that demand reliable, network-ready amplification
| Pair | 3 Mc2 Delta 80 DSP, 3 Mc2 Delta 40 SLAVE |
|---|
